6061 Aluminum Plate/Sheet
6061 aluminum plate is made of a high-quality aluminum alloy product that has undergone heat treatment and pre-stretching process. 6061 aluminum plate has excellent processing performance, corrosion resistance, high toughness and no deformation after processing. It has excellent features such as easy color film application and excellent oxidation effect.
6061 Aluminum Plate/Sheet
Name | 6061 Aluminum Plate/Sheet |
Standard | JIS G3141,DIN1623,EN10130 |
Material | 1050,1060,3003, 3A21,5052.5005.5083.5A05,6061.etc |
Sheet | 0.15 mm- 2.0mm |
Normal sheet | 2.0mm-6.0mm |
Medium plate | 6.0 mmt-25.0mm |
Plate | 25mm-200mm Super thick plate more than 200mm |
Packing | Export standard packing or according to customers’ requirement |
Certificate | ISO9001:2008,SGS |
Chemical Composition
Alloy | %Si | %Mg | %Mn | %Cu | %Fe | %Cr | %Zn | %Ti | %Others | %Al |
EN AW-1050 A | 0.25Max | 0.05Max | 0.05Max | 0.05Max | 0.40Max | – | 0.07Max | 0.05Max | – | 99.5 Min |
EN AW-1070 A | 0.20Max | 0.03Max | 0.03Max | 0.03Max | 0.25Max | – | 0.07Max | 0.03Max | – | 99.7 Min |
EN AW-1100 | Si+Fe 0.95 Max | – | 0.05 Max | 0.05 – 0.20 | – | – | 0.10 Max | 0.05 Max | – | 99.0 Min |
EN AW-2011 | 0.40 Max | – | – | 5.00 – 6.00 | 0.70 Max | – | 0.30 Max | – | Bi : 0.20 – 0.60Pb : 0.20 – 0.60 | Remainder |
EN AW-2014 | 0.50 – 1.20 | 0.20 – 0.80 | 0.40 – 1.20 | 3.90 – 5.00 | 0.70 Max | 0.10 Max | 0.25 Max | 0.15 Max | – | Remainder |
EN AW-2024 | 0.50 Max | 1.20 -1.80 | 0.30 – 0.90 | 3.80 – 4.90 | 0.50 Max | 0.10 Max | 0.25 Max | 0.15 Max | 0.15 Max | Remainder |
EN AW-3003 | 0.60 Max | – | 1.00 – 1.50 | 0.05 – 0.20 | 0.70 Max | – | 0.10 Max | – | 0.15 Max | Remainder |
EN AW-3103 | 0.50 Max | 0.30 Max | 0.90 – 1.50 | 0.10 Max | 0.70 Max | 0.10 Max | 0.20 Max | 0.10 Max | – | Remainder |
EN AW-6101A | 0.30 – 0.7 | 0.40 – 0.90 | 0.03 Max | 0.05 Max | 0.40 Max | – | – | – | 0.10 Max | Remainder |
EN AW-6005 | 0.60 – 0.90 | 0.40 – 0.60 | 0.10 Max | 0.10 Max | 0.35 Max | 0.10 Max | 0.10 Max | 0.10 Max | – | Remainder |
EN AW-6351 | 0.70 – 1.30 | 0.40 – 0.80 | 0.40 – 0.80 | 0.10 Max | 0.50 Max | – | 0.20 Max | 0.20 Max | 0.15 Max | Remainder |
EN AW-6060 | 0.30 – 0.60 | 0.35 – 0.60 | 0.10 Max | 0.10 Max | 0.10 – 0.30 | 0.05 Max | 0.15 Max | 0.10 Max | – | Remainder |
EN AW-6061 | 0.40 – 0.80 | 0.80 – 1.20 | 0.15 Max | 0.15 – 0.40 | 0.70 Max | 0.04 – 0.35 | 0.25 Max | 0.15 Max | – | Remainder |
EN AW-6063 | 0.20 – 0.60 | 0.45 – 0.90 | 0.10 Max | 0.10 Max | 0.35 Max | 0.10 Max | 0.10 Max | 0.10 Max | – | Remainder |
EN AW-6082 | 0.70 – 1.30 | 0.60 -1.20 | 0.40 – 1.00 | 0.10 Max | 0.50 Max | 0.25 Max | 0.20 Max | 0.10 Max | – | Remainder |
Mechanical Properties
Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
EN AW-1050 A | F | 60 | – | 20 | – | 23 |
O | 60 | 95 | 20 | – | 23 | |
EN AW-1070 A | F | 60 | – | 20 | – | 23 |
EN AW-1100 | O | 75 | 110 | – | – | 25 |
EN AW-2011 | T4 | 275 | – | 125 | – | 12 |
T6 | 310 | – | 230 | – | 6 | |
EN AW-2014 | O | – | 250 | – | 135 | 10 |
T4 | 370 | – | 230 | – | 11 | |
T6 | 415 | – | 370 | – | 5 | |
EN AW-2024 | O | – | 250 | – | 150 | 10 |
T3,T3510,T3511 | 395 | – | 290 | – | 6 | |
T8,T8510,T8511 | 455 | – | 380 | – | 4 | |
EN AW-3003 | F | 95 | – | 35 | – | 20 |
O | 95 | 135 | 35 | – | 20 | |
EN AW-3103 | F | 95 | – | 35 | – | 20 |
O | 95 | 135 | 35 | – | 20 | |
EN AW-6101A | T6 | 200 | – | 170 | – | 8 |
EN AW-6005 | T4 | 180 | – | 90 | – | 13 |
T6 | 270 | – | 225 | – | 6 | |
EN AW-6351 | O | – | 160 | – | 110 | 12 |
T4 | 205 | – | 110 | – | 12 | |
T6 | 290 | – | 250 | – | 6 | |
EN AW-6060 | T4 | 120 | – | 60 | 14 | 12 |
T5 | 160 | – | 120 | – | 6 | |
T6 | 190 | – | 150 | – | 6 | |
T64 | 180 | – | 120 | – | 10 | |
T66 | 215 | – | 160 | – | 6 | |
EN AW-6061 | O | – | 150 | – | 110 | 14 |
T4 | 180 | – | 110 | – | 13 | |
T6 | 260 | – | 240 | – | 6 | |
EN AW-6063 | O | – | 130 | – | – | 16 |
T4 | 130 | – | 65 | – | 12 | |
T5 | 175 | – | 130 | – | 6 | |
T6 | 215 | – | 170 | – | 6 | |
T66 | 245 | – | 200 | – | 6 | |
EN AW-6082 | O | – | 160 | – | 110 | 12 |
T4 | 205 | – | 110 | – | 12 | |
T5 | 270 | – | 230 | – | 6 | |
T6 | 290 | – | 250 | – | 6 |
